Bode 500 VNA
Now available, the long-awaited Bode 500 VNA!
The Bode 500 is the most powerful analyzer from OMICRON Lab. Its ultra-wide frequency range enables precise measurements from <1 Hz up to 450 MHz.
Bode 100 Vector Network Analyzer
With the multifunctional Bode 100 you get an exact picture of your electronic circuits and components in a frequency range from 1 Hz to 50 MHz.
Measurement solutions
for your power integrity needs
Turn your scope into a TDR
with the PerfectPulse® Differential TDR
- Cable/Connector Tester
- PCB/Coupon/Trace/Impedance Tester
- Probe Calibration
- Single or Differential Operation
- Fast edge generation for DSP correction
Train. Grow. Succeed.
Picotest online training.
A collection of classes, application notes, articles and presentations and demonstration videos.
Master the Fundamentals of Power Integrity and Power Supply Testing
This course is now available on-demand and covers how to master the most important power supply measurements including those associated with Power Integrity and today?s power distribution systems.
The topics and tests are discussed in detail with a variety of lab demonstrations.
Featured Insights
The Challenge of Measuring a 40 µohm, 2000 Amp PDN With a 2-Port Probe: How Much CMRR is Needed?
Benjamin Dannan, Signal Edge Solutions and Steve Sandler, Picotest Published in Signal Integrity Journal A two-part series of posts, firstly determining how much CMRR is needed…
Picotest Pocket TDR Fills Important Niche
A time domain reflectometer (TDR) is generally a large, expensive benchtop instrument that measures impedance, PCB coupons, dielectric constants, PCB signal traces, interconnects, connectors,…
Picotest Releases Line of High-Speed Transient Load Steppers for VRM and PDN Validation
In a major technological leap, Picotest, maker of custom test equipment for power integrity and power systems testing, has released a series of very…
Power Integrity
Measuring, Optimizing, and Troubleshooting Power-Related Parameters in Electronics Systems
By Steven Sandler
Publications
Power Integrity Provides engineers with expert insight on selecting and implementing appropriate test equipment to effecrively measure increasingly higher speed electronics. The book contains field-tested information related to the interpretation of results, common measurement issues and resolutions.
Measurement Solutions Videos
PicoSlammer Transient Load Stepper
High speed power supply load stepping is the newest demanding frontier for test adapters. Very fast load stepping for hundreds or even thousands of amps are needed to test the power supply driving today’s and tomorrow’s high-speed processor solutions.
Why specialized PDN Cable® is Essential for your Power Integrity Impedance Testing
This short video discusses the feature set your cabling needs to get PDN impedance measurements correct.
Performing a 2-port shunt-through impedance measurement on the CMT Compact VNA
Copper Mountain Technologies’ VNAs Gain Non-Invasive Stability Measurement – NISM
